Protocol 31729 - Tg(APP)-alternate1

Notes

Taqman qPCR protocols are run on a real time PCR instrument. Use an appropriate instrument specific Fluorophore/Quencher combination. The transgene genotype is determined by comparing ΔCt values of each unknown sample against known homozygous and hemizygous controls, using appropriate endogenous references.

The genotyping protocol(s) presented here have been optimized for reagents and conditions used by The Jackson Laboratory (JAX). To genotype animals, JAX recommends researchers validate the assay independently upon receipt of animals into their facility. Reaction cycling temperature and times may require additional optimization based on the specific genotyping reagents used.

Expected Results

Tg= 185 bp

IPC = 74 bp

JAX Protocol

Protocol Primers

Primer	5' Label	Sequence 5' → 3'	3' Label	Primer Type	Reaction
20647		TGG GTT GAC AAA TAT CAA GAC G		Transgene Forward	A
37506		TGA CGA TCA CTG TCG CTA TGA		Transgene Reverse	A
oIMR1544		CAC GTG GGC TCC AGC ATT		Internal Positive Control Forward	A
oIMR3580		TCA CCA GTC ATT TCT GCC TTT G		Internal Positive Control Reverse	A
TmoIMR0076	Fluorophore-1	CAT TGG ACT CAT GGT GGG CGG TG	Quencher-1	Tg Probe
TmoIMR0105	Fluorophore-2	CCA ATG GTC GGG CAC TGC TCA A	Quencher-2	IC Probe

Reaction A

Component	Final Concentration
Kapa Probe Fast QPCR	1.00 X
ddH2O
20647	0.40 uM
37506	0.40 uM
oIMR1544	0.40 uM
oIMR3580	0.40 uM
Tg Probe	0.15 uM
IC Probe	0.15 uM
DNA

Cycling

Step	Temp °C	Time	Note
1	95.0	--
2	95.0	--
3	60.0	--	repeat steps 2-3 for 40 cycles

JAX uses a very high speed Taq (~1000 bp/sec), use cycling times recommended for your reagents.

Strains Using This Protocol

This is the only strain that uses this protocol.
